Stamping press flexibility takes into consideration the need to reduce time and risks of changeover by adopting an automatic die change system with movable tables that allows a machine to be fast fitted by a hydraulic die locking system to minimize machine set-up time.
The machine structure has many accuracy levels, in particular to table planarity, parallelism between the main slide and the table and the cylinder sliding along guides; Very tight tolerances of around 5/100 allow a significant reduction of wear of the dies and all the rest of machine moving parts.
Another important contribution to the high performance level of EV/1000 press comes from a numerical control that is able to handle 3 functions (action), with relevant pressure cycles; In addition to the upper and lower cylinders, the press is equipped with a third cylinder, used for fine-tuning, blanking, for workpiece ejection and many other tasks. Remarkable attention to environmental issues led our design and software team to introduce functions, as: automatic switch-off of the motors after 20 minutes of inactivity, automatic detection of oil leakages, high performance (excellent ratio developed speed/used power).
